Price Of Industrial Electric Heat Treatment Muffle Furnace / Lab Furnace
|
Model
|
LY-612
|
LY-625
|
LY-630
|
LY-640
|
LY-X
|
|
Chamber size
(W*H*D)cm
|
12*8*20
|
25*16*40
|
30*20*50
|
40*40*60
|
Which can be customized
|
|
Temperature Range
|
RT~1800℃(Standard one is to 1200℃)
If you need higher temperature, please let us know, it can be customized
|
||||
|
Heating Up Time
|
RT~1200℃ About 50 min
|
||||
|
Temperature Accuracy
|
±1℃
|
||||
|
Heat Element
|
Top quality resistance wire, based on temperature range, we also offer other heating element like silicon carbide rod, SiC heater, MoSi2 heater etc.
|
||||
|
Thermal Couple
|
Type K, Type S, Type B etc.
|
||||
|
Temperature Control
|
• PID automatic control and auto-tune function.
• 31 or 51 programmable segments for precise control.
• Built in protection for over-heated and broken Thermal couple.
• Larger digital control panel (48 x 96 mm) for easy operation.
|
||||
|
Furnace Structure
|
•high purity ceramic fibre insulation (energy saving 40% and weight lighter about 30% than old furnace);
• Double layers steel casing with fan cooling, to ensure the surface of furnace below 50℃.
|
||||
