LIYI 150L Constant Temperature Humidity Test Chamber 3 Phase 380V 50/60HZ

1 Set
MOQ
4000~10000USD
Price
LIYI 150L Constant Temperature Humidity Test Chamber 3 Phase 380V 50/60HZ
Features Gallery Product Description Request A Quote
Features
Specifications
Material: 304# Stainless Steel
Volumn: 150L
Voltage: 3 Phase 380V
Accuracy: 0.5℃ ±2.5%RH
Temperature Range: -40°C~150°C/-70°C~150°C
Humidity Range: 20%~98% / 5%~98%
Heating Rate: Standard Around 3°C/min (can Customize)
Cooling Rate: Standard Around 1°C/min (can Customize)
High Light:

150L climate control chamber

,

380V environmental simulation chambers

Basic Infomation
Place of Origin: China
Brand Name: LIYI
Certification: CE
Model Number: LY-2150
Payment & Shipping Terms
Packaging Details: Plywood pallet box
Delivery Time: 15-30 working days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 100 sets per month
Product Description

LIYI 150L Constant Temperature Humidity Test Chamber 3 Phase 380V 50/60HZ

      CE Certificated 150L Constant Temperature And Humidity Stability Test Chamber In Stock is used to test the material characteristic for wire type, skin type, plastic, rubber, cloth, Equiped with a special ventilation regulator for maintain the fresh air inside when heating. This testing machine design with sophisticated air-displacement adjustment device and a digital voltage meter, current meter, watt-hours, the timer can be used to measure the air replacement rate. Horizontal circulatory air supply system and both sides of airflow regulator to ensure the internal temperature uniformity and stability.

      It is applied to test the prodcuts quality, such as electronic, plastic products, electrical appliances, instruments, food, vehicles, metals, chemicals, building materials, aerospace, medical care and so on.

Standards:
● GB-2423.1-2008 (IEC68-2-1)Test A: Low Temperature Test
● GB-2423.2-2008(IEC68-2-2)Test B: High Temperature Test
● GJB360.8-2009(MIL-STD.202F) High Temperature Life Test
● GJBl50.3-2009(MIL-STD-810D) High Temperature Test
● GJBl50.4-2009 (MIL-STD-810D) Low Temperature Test
● GB2423.3-2008(IEC68-2-3)Test Ca: Constant Heat Test
● GB2423.4-2008(IEC68-2—30) Test Db: Damp Heat Alternative Test
● GJBl50.9-2009 (MIL-STD-810D) Damp Heat Test

Specifications:

Model LY-280 LY-2150 LY-2225 LY-2408 LY-2800 LY-21000
Inner Size W×H×D(cm) 40×50×40 50×60×50 50×75×60 60×85×80 100×100×80 100×100×1000
External Size W×H×D(cm) 93×155×95 100×148×106 117×166×118 122×176×121 158×186×148 158×195×168
Volume(L) 80 L 150L 225L 408L 800L 1000L
Temp&Humi Control Range

Temp. Range: A: -20℃~100℃ humidity range: 20%~98%

B: -40℃~150℃

C: -70℃~150℃

(Other temperature and humidity range can be customized)

Temp&Humi Fluctuation ±0.5℃;±2.5%RH
Temp&Hum Departure ±0.5℃-±2℃;±3%RH(>75%RH); ±5%RH(≤75%RH)
Controller Resolution ±0.3℃;±2.5%RH
Controller Brand LCD touch screen controller
Material In side wall SUS 304# stainless steel plate
Housing Steel plate surface fog processed or color painted
Heat Insulator resistance to high temperature, high chlorine acid b vinegar foam insulation materials
Air Circulation Way centrifugal fan-broadband type force air circulation
Refrigeration Way cascade type multiple refrigeration
Refrigerator fully enclosed piston compressor Tecumseh France
Refrigerants R4O4Aor American Dupont environmental protection cold media(R23+R404)
Condensing Way Air-cooling
Heater nickel chrome heating wire heater
Humidifier semi-closed steam
Water Supply Way automatic cycle water supply
Standard Accessories

* 50mm test hole on the left............................................................1PCS
* PL inner lamp................................................................................1PCS
* Adjustable clapboard.....................................................................2PCS
* Humidity cloth...............................................................................1Bag
* Fuses..............................................................................................3PCS
* Power line.......................................................................................1PCS
* Software CD....................................................................................1PCS
* Operation manual.............................................................................1PCS

Safety Devices

* Leakage current
* Overload
* Compressor overload
* Over temperature
* Ultra-wet/dry
* Humidification temperature protection.

Power Single phase 220V AC±10% 50/60HZ

LIYI 150L Constant Temperature Humidity Test Chamber 3 Phase 380V 50/60HZ 0

Features:
1. Graceful appearance, circularly shaped body, surface treated with mist strips and plane handle with no reaction. Easy to operate, safe and reliable.
2. Rectangular double-glassed watching window for the observation of the test production during the testing process. The window is equipped with sweat-proof electrical heating device that can prevent water steam from condensing into droplets, and with high brightness PL fluorescent bulbs to provide light inside the box.
3. Double-layer-insulated airtight doors, able to insulate the internal temperature effectively.
4. Water supply system that is externally connectable, convenient for refilling water into the humidifying pot and automatically recyclable.
5. The French Tecumseh brand is used for the circulation system of the compressor, capable of removing the lubricant between the condensation pipes and capillaries. The environment-protecting coolant is used for the whole
series (R232,R404)
6. Imported LCD display screen, capable of displaying the measured value as well as the set value and time.
7. The control unit has the functions of multiples segment program editing, and of quick or slope control of temperature and humidity.
8. Inserted mobile pulley, convenient for movement an relocation, with strong positioning screws


What you will get:

• LED Touch Screen

• PID Control of Temperature and Humidity

• Both Temperature and Humidity are Programmable (can have 100pattern, each pattern has 999 segment)

• With Humidity Sensor

• With RS485/232 output to computer

• Window Software

• Remote fault notification(opntional)

• With Viewing Window

• With thermostats (prevent overheat)

• Cable Ports(50mm diameter)

• With Data Storage fuction by USB Flash Memory

• Protection (phase protection, overheat, overcurrent etc)

• Water Tank with level detector

• Adjustable Shelf

• Anti-condensation technology of the workroom .(Optional)

• User friendly three color LED indicator lamp ,easy to read working condition


LIYI 150L Constant Temperature Humidity Test Chamber 3 Phase 380V 50/60HZ 1

FAQ:

1. Are your a trading company or a factory?
Re: We are factory with 15 years manufacturing experience and export to more than 100 countries all over the world in past 9 years or exporting..

2. After an order is placed, when to deliver?
Re: Generally about 20-30 working days, standared products most of time we can arrange shipment within 3 working days.

3. What about the warranty with after - sales services?
Re: 12 months free warranty.
After the warranty, the professional after-sale service team will provide perfect technical support,and help customer solve problems encountered while using our product, handles guest problems and complaints in a professional and timely.

4. What about the services and product' quality?
Re:Service: OEM service,Design service,Buyer lable service.Quality: Each instruments must be carried out 100% quality examination and test, the finished products must through a third party calibration institutions before shipping and delivery goods.

5. How to install and training?
Re: If the products is easy to install and training, customers can learn the operation and maintenance manual to installation and use.
If the products is hard to use, customers can come LIYI factory to learn how to installation and use.

Customer can also choose to require our engineer to go for onsite installation if needed.
