LIYI 500C Industrial Drying Oven Safety Helmets Pretreatment Electric Blast Drying Oven

1 Set
MOQ
1000~10000USD
Price
LIYI 500C Industrial Drying Oven Safety Helmets Pretreatment Electric Blast Drying Oven
Features Gallery Product Description Request A Quote
Features
Specifications
Material: 304# Stainless Steel
Inner Size: All Size Can Be Customized
Max Temperature: RT~200/300/400/500C Optional
Inner Structure: 2 Stainless Steel Shelves(can Customize)
Controller: PID Or PLC Optional
Color: White (can Customize)
OEM: Offered
Heater: Electrical Heater
Voltage: 220V Or 380V
Warranty: 1 Year
High Light:

500C Industrial Drying Oven

,

500C electric blast drying oven

,

Pretreatment Industrial Drying Oven

Basic Infomation
Place of Origin: China
Brand Name: LIYI
Certification: CE
Model Number: LY-6100
Payment & Shipping Terms
Packaging Details: Plywood pallet box
Delivery Time: 15-30 working days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 100 sets per month
Product Description

LIYI 500C Industrial Drying Oven Safety Helmets Pretreatment Electric Blast Drying Oven



Product description:

       Full SUS 304 Stainless Steel High Temperature Pretreatment Oven Chamber for Safety Helmets is very versatile pieces of equipment with applications in laboratory research, engineering, and industry. Drying oven is most often used for delicate drying processes, such as drying tiny parts or removing flammable solvents. A standard drying oven can operate at temperatures as high as 200°C to 300°C.



Characteristics:

1. All SUS#304 stainless steel, outer material is well coated steel plates.
2. The door sealing uses silicone, which endures high temperation. View window attached. (Optional)
3. The centrigugal fan can provide greater cyclic airflow to avoid dead corner in the chamber so as to obtain uniform distribution of temperature.
4. PID controller, double sided overheating protection.
5. Multiple loading shelves to support the testing samples.
6. Floor standing with removeable casters, easy to move and adjust height.
7. Timer: temperature to timing, easily control the operation period.



Specifications:

Model

Inner Size

W*H*D(cm)



External Size

W*H*D(cm)



Temperature

Range(°C)

Heating

up

Time

Accuracy

(°C)

Uniformity

(°C)

Power

Rate of

work

(kw)

LY-645 45×40×40 66×92×55



(A-D)

A:200°C

B:300°C

C:400°C

D:500°C





RT~100°C

About 10min

±0.3 ±1%

220V

Or

380V

3.5
LY-660 50×60×50 70×125×65 ±0.3 ±1% 4.5
LY-690 60×90×50 80×156×65 ±0.3 ±1% 5.5
LY-6100 80×100×60 100×166×75 ±0.3 ±1% 8
LY-6120 90×120×60 110×186×75 ±0.3 ±1% 10
LY-6140 140×120×60 160×186×75 ±0.3 ±1% 12
LY-6160 160×140×80 180×206×97 ±0.3 ±1% 14
LY-6180 180×140×100 200×200×118 ±0.3 ±1% 16





LIYI 500C Industrial Drying Oven Safety Helmets Pretreatment Electric Blast Drying Oven 0



LIYI 500C Industrial Drying Oven Safety Helmets Pretreatment Electric Blast Drying Oven 1



LIYI 500C Industrial Drying Oven Safety Helmets Pretreatment Electric Blast Drying Oven 2



LIYI 500C Industrial Drying Oven Safety Helmets Pretreatment Electric Blast Drying Oven 3



LIYI 500C Industrial Drying Oven Safety Helmets Pretreatment Electric Blast Drying Oven 4



Our service:

If you face any problems in future during testing process we promise we will give you a reply within 48 hours and solution provide within 3 working days. We can offer operation video and English operation manual. We can provide video-con.
1. Considerate Service Different countries plugs, manually change the-voltage from 110V to 220V, insurance indicator.
2.Excellent After sale Service: 12 months warranty. Besides, we can help you to repair your problem controller freely, even it's not from our factory. What you need to do is to send us the controller.
3.Commitment:We will sign a letter of commitment while we sign the contract, which will improve your confidence to us.
4.Good Packaging:
Simulation Animatronic Customer Triceratops are covered with air bubble film before put them into the wooden case, which not only has good shock absorption, impact resistance, heat sealing and also has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
