LIYI UV Lamp Aging Irradiation Adjustable Test Chamber Machine Environmental Testing Chamber
UV aging test machine can provide reliable aging test data to make the exact prediction of products' weathering fastness(ageing resistance)., which is conducive to sift and optimize the formula.
Designing Standard:
IEC61215, ASTM D4329,D499,D4587,D5208,G154,G53；ISO 4892-3,ISO 11507；EN 534；prEN 1062-4,BS 2782；JIS D0205；SAE J2020,ect.
Characteristics:
1.The UVA340 Ultraviolet Environmental Simulation Chamber for Ink Aging Test with 40W UVA Lamps is designed according to uses’ operation , it’s easy to operate, safe and reliable.
2.The thickness of specimen installation is adjustable and the specimen installation is fast and convenient.
3.The door rotating up does not interfere with the operation and the tester takes a very small space only.
4.It’s unique condensation system can be contented by tap water.
5.The heater is under the container rather than in the water, which is long life, easy to maintain.
6.The water level controller is outside the box, easy to monitor.
7.The machine has truckles, convenient to move.
8.Computer programming is convenient, automatically alarming when incorrect operated or faulted.
9.It has irradiance calibrator to extend the life of the lamp tube(more than 1600h).
10.It has Chinese and English instruction book, convenient to consult.
11.Divided into three types: common, light irradiance controlling, spraying
Specifications:
| Mode | LY-ZW | |
| Inside Dimensions (CM) | 45×117×50 | |
| Outer Dimensions (CM) | 70×135×145 | |
| Rate of Work | 4.0(KW) | |
|
Performance Index
|
Temperature Range | RT＋10℃～70℃ |
| Humidity Range | ≥95％R.H | |
| Distance Between Lamps | 35mm | |
| Distance Between Samples and Lamps | 50mm | |
| Specimen Number | L150mm×W75mm, 48pcs in total | |
| Ultraviolet Wavelength | 290nm～400nm UV-A340,UV-B313,UV-C351(state clearly in your order ) | |
| Rate of the Lamp | 40W/Piece, 1200mm/Piece | |
| Lamp amount | 8pcs | |
|
Controlling System |
Controller | touch screen programmable controller |
| Illumination Heating System | all independent system, nickel chrome alloy electrical heating type heater | |
| Condensation Humidifying System | stainless steel shallow evaporative humidifier | |
| Blackboard Temperature | double metal blackboard thermal meter | |
| Water Supplying System | Humidification water supplying automatic control | |
| Exposure Way | moisture condensation way exposure, light radiation exposure | |
| Safety Device | leakage, short circuit, super temperature, water shortage and over current protection | |
Company Information:
Dongguan LIYI Environmental Technology Co.,Ltd is a high technology supported production-oriented enterprise, which is wstablished in 2008.
Liyi manufactures testig machines like Environmental Chambers, Industrial Ovens, Universal Tensile Testing Machines, UV Aging Test Chambers, Industrial Muffle Furnace, Paper Packing Testrs, Plastic Rubber Testers, Adhesive Testers and other testing Equipments.
During the whole business process, we offer Consultative Selling service.
1)Customer inquiry process:
Discussing testing requirements and technic details, suggested suitable products to customer to confirm. Then quote most suitable price according to customer requirements.
2)Specifications customize process:
Drawing related drawings to confirm with customer for customized requirements. Offer reference photoes to show the proucts appearance. Then, confirm the final solution and confirm final price with customer.
3)Order process:
We offer below business term:
| Accepted Delivery Terms: | FOB, CFR, CIF, EXW, DDP |
| Accepted Payment Currency: | USD, EUR, HKD, CNY |
| Accepted Payment Type: | T/T, L/C, Credit Card, PayPal, Western Union, Cash, Escrow |
| Nearest Port: | Shenzhen, Guangzhou, Shanghai, Qingdao, Tianjing or rquired |
4)Production and delivery process:
We will produce the machines according to confirmed PO requirements. Offering photoes to show production process.
After finish production, offer photoes to customer to confirm again with the machine. Then do own factory calibration or third party calibration(as customer requirements). Check and test all the details and then arrange packing.
Deliver the products in confirmed shipping time and inform customer.
5)Installation and after sale service:
Defines installing those products in the field and providing after-sales support.
