1-2m/Min Adhesive Tape Hot Melt Roll Coater LIYI Lab Scale Simulations
1 set
MOQ
6,580.00 - $9,800.00
Price
1-2m/Min Adhesive Tape Hot Melt Roll Coater LIYI Lab Scale Simulations
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China
Brand Name: LIYI
Certification: ISO,CE
High Light:

2m/Min hot melt roll coater

,

LIYI hot melt roll coater

,

LIYI hot melt adhesive coating machine

Payment & Shipping Terms
Packaging Details: Packing in wooden cases
Delivery Time: 15 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100 sets one month
Specifications
Dimension(L*W*H): 1200*620*550mm
Warranty: 12 Months, 1 Year
Power Source: 1 Phase, AC 220V/330V
Certificate: CE ISO
Voltage: 220V/380V
Weight: 120 KG
Product Description

LIYI Samples Making Adhesive Tape Hot Melt Coater Use Fabric Roll Spin Coating Machine

Product Description



The Hot Melt Coater is capable of producing coated samples or small production of hot melt adhesives, and then laminating to a variety of foils, films, and papers. Lab scale simulations of production processes can be easily set up and studied. Continuous coating proofing or small production of laboratory miniature hot melt adhesive coating and laminating machine. The hot-melt pressure sensitive adhesive can be directly coated on the heat-resistant substrate, or coated on the release paper and then applied to different surfaces, such as paper, plastic model metal film, etc. (50 μ m high temperature resistant PET film is recommended for the best experimental substrate).

Specification



Maximum operating temperature 200
The maximum coating width 200mm
the maximum width of the sheet 260mm
the maximum width of coating 160 mm
The coating length unlimited
Coating speed

adjustable, max coating speed: 4.5m/min,

the most suitable speed is 1-2m/min,

Max capacity 150g
Minimum coating thickness 0.05mm
The maximum gap of total coating 500 μ m(base material thickness)
the optimum coating thickness ≥ 20 μ m
coating accuracy ±5 μ m
Dimension 150×518(Containing motor 720)×658mm(L*W*H)
Weight about 120kg
Power source 1 phase, AC 220V,50HZ
Rate of power 1050W
