Liyi High Temperature Industrial Forced Circulation Electric Blast Drying Oven for Carbon Fiber Glass Led Curing Oven
Product Specifications
| Attribute |
Value |
| Type |
Drying Oven |
| Application |
Chemicals Processing, Plastics Processing |
| Voltage |
220V |
| Warranty |
1 Year |
| Weight |
200 kg |
| Core Components |
Engine |
| Heating Method |
Electric Heating |
| Material |
SUS304 |
| Accuracy |
±0.3 |
| Heating Rate |
RT~100°C about 10min |
| Temperature Range |
RT~200°C/300°C/400°C/500°C/600°C/800°C |
| Control System |
Microcomputer PID |
Product Description
With many years of experience, we design, manufacture and trade high-quality industrial ovens at affordable prices. Our industrial ovens are designed to heat up to 800°C and are used for various heat processes including drying, curing, aging, annealing, stress relieving, bonding, tempering, pre-heating and forming.
Industrial ovens are essentially heated boxes with insulated doors that process products individually or in batches. The parts to be heated are brought into the oven in batches on racks, carts, or trucks. Production requirements can accommodate manual or automated loading.
Standard industrial ovens are offered in many sizes, with multiple options available upon request. We also supply custom engineered industrial ovens.
Standard Models (Temperature Range RT~500°C, customizable up to 800°C)
| Model |
Inner Size (W×H×D cm) |
External Size (W×H×D cm) |
Accuracy (°C) |
Uniformity (°C) |
Power (KW) |
| LY-645 |
45×40×40 |
66×92×55 |
±0.3 |
±1% |
3.5 |
| LY-660 |
50×60×50 |
70×125×65 |
±0.3 |
±1% |
4.5 |
| LY-690 |
60×90×50 |
80×156×65 |
±0.3 |
±1% |
5.5 |
| LY-6100 |
80×100×60 |
100×166×75 |
±0.3 |
±1% |
8 |
| LY-6120 |
90×120×60 |
110×186×75 |
±0.3 |
±1% |
10 |
| LY-6140 |
140×120×60 |
160×186×75 |
±0.3 |
±1% |
12 |
| LY-6160 |
160×140×80 |
180×206×97 |
±0.3 |
±1% |
14 |
| LY-6180 |
180×140×100 |
200×200×118 |
±0.3 |
±1% |
16 |
| LY-OEM |
All aspects depend on your requirements! |
Product Images
Frequently Asked Questions
1. Are you Manufacturer? Do you offer after-sales service? How can I ask for that? And how about the warranty?
Yes, we are one of the professional and largest manufacturers of environmental chambers, industrial ovens, universal tensile testers, UV aging test chambers, industrial muffle furnaces, and other testing equipment. Every machine purchased from our factory has 12 months warranty after shipment. We offer 12 months of free maintenance, with an additional 2 months extension considering sea transportation.
If your machine doesn't work, you can contact us via email or phone. We will diagnose the problem through conversation or video chat if necessary. Once confirmed, a solution will be offered within 24 to 48 hours.
2. What's the delivery term?
For standard machines in stock, we can ship immediately. If no stock is available, normal delivery time is 15-20 working days after deposit receipt. Urgent orders can be specially arranged.
3. Do you accept customization service? Can I have my logo on the machine?
Yes, we offer both standard and customized machines according to your requirements. We provide OEM and ODM services, including adding your logo to the machine.
4. How can I install and use the machine?
Most machines are shipped fully assembled - you just need to connect the power cable to start using. We provide English operation videos via email. If necessary, we can assist with on-site installation.
