LIYI 1700 Degree Electric Drying Oven 220V/60HZ LIYI Inert Gas Atmosphere Furnace

1 Set
2,680.00 - 4,980.00USD
LIYI 1700 Degree Electric Drying Oven 220V/60HZ LIYI Inert Gas Atmosphere Furnace
Features Gallery Product Description Request A Quote
Warranty: 12 Months
Classification: Laboratory Heating Equipments
Customized Support: OEM
Temperature Range: RT~1800°C
Accuracy: ±1
Power: 220V Or 380V
Volumn: Customize
Theory: Temperature Controller
Voltage: 380V/50HZ 220V/60HZ
Color: Customers' Requirements
High Light:

1700Degree Electric Drying Oven


220V 60HZ Electric Drying Oven


LIYI Inert Gas Atmosphere Furnace

Basic Infomation
Place of Origin: Guangdong, China
Brand Name: LIYI
Certification: CE, ISO
Payment & Shipping Terms
Packaging Details: Plywood pallet box
Delivery Time: 30-40 Working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100 sets per months
Product Description

LIYI 1700 Degree Electric Drying Oven 220V/60HZ LIYI Inert Gas Atmosphere Furnace



Product Description

This series of equipment is suitable for scientific research institutions, colleges and universities, industrial and mining enterprises ideal experimental and production equipment. It mainly used in high temperature precision annealing, micro-crystallization, ceramic glaze preparation, mold annealing, powder metallurgy, plastic powder foam test, sintering of nanometer materials, quenching of metal parts and all heat treatment required by high temperature technology.



1. The double-layer forced air-cooling structure of the furnace shell is close to the room temperature at the time of operation. The appearance is sprayed with high-temperature and high-quality paint, and is not easy to fade. The door of the furnace is protected by stainless steel cover for a long time without blackening and easy to maintain.

2. Integrated compact design, step splicing structure, in accordance with the law of mechanics, heating force is uniform, heat is not easy to lose.

3. High quality and high alumina polycrystalline ceramic fiber (alumina > 95%), resistant to rapid cooling and heat preservation



Model LY-16-17TP LY-16-18TP LY-16-19TP
Furnace size(W*H*D)mm 150*150*80 200*150*150 300*200*200
Outer size(W*H*D)mm 735*750*1200 700*670*930 750*660*1020
Weight(Kg) 155 190 300
power rating 3KW 5KW 9KW
Power 220V 50/60HZ
Temperature control precision ±1
vacuum degree -0.1MPa
end-use temperature maximum temperature 1800℃
heating rate 0--30℃/min(recommended less than 20/min)
Thermocouple Type B
heating element Silicon molybdenum rod
Display mode Color LED display
gasket ring Fluorine ring
vacuum pump Oil-immersed single rotary vane vacuum pump
Measuring mode mechanical pressure gauge
Furnace material High alumina polycrystalline ceramic fiber
Furnace structure double-layer forced air-cooling structure


LIYI 1700 Degree Optional Sizes With Vacuum Pump Inert Gas Atmosphere Vacuum Muffle Furnace



Company Information

Guangdong LIYI Technology Co.,Ltd is a high technology supported production-oriented enterprise who specializes in developing, manufacturing, marketing all kinds of environmental equipment. Our company has advanced technology, experienced technical management personnel and efficient professional service staffs, fine quality management and perfect after-sales service system.

Our company mainly produce simulated environmental tester, plastic and rubber tester etc. on all kinds of materials testing industries. The production base is located in the country’s manufacturing center Dongguan, Guangdong province, China. In order to service our customers better in terms of reducing costs and early delivery, in 2005 we had set up an office in Kunshan, Jiangsu province for Eastern China marketing and servicing.

Liyi deals with customers from more than 150 countries and regions. Meanwhile, we are committed to cooperate with different dealers in different countries and regions in order to offer better service. Our mission is to help every customers establish testing labs to ensure the quality of their products.

Our company will continue to develop, innovate and keep faith. We combine with the international testing standards and the specific demands of customers that may establish a new banner in Chinese testing industry.

LIYI 1700 Degree Optional Sizes With Vacuum Pump Inert Gas Atmosphere Vacuum Muffle Furnace
