LIYI 1000-1800Degree Electric Drying Oven LIYI Inert Atmosphere Heat Treatment

1 Set
MOQ
2,680.00 - 4,980.00USD
Price
LIYI 1000-1800Degree Electric Drying Oven LIYI Inert Atmosphere Heat Treatment
Features Gallery Product Description Request A Quote
Features
Specifications
Warranty: 12 Months
Classification: Laboratory Heating Equipments
Customized Support: OEM
Temperature Range: RT~1800°C
Accuracy: ±1
Power: 220V Or 380V
Volumn: Customize
Theory: Temperature Controller
Voltage: 380V/50HZ 220V/60HZ
Color: Customers' Requirements
High Light:

1000Degree Electric Drying Oven

,

1800Degree Electric Drying Oven

,

LIYI inert atmosphere heat treatment

Basic Infomation
Place of Origin: Guangdong, China
Brand Name: LIYI
Certification: CE, ISO
Payment & Shipping Terms
Packaging Details: Plywood pallet box
Delivery Time: 30-40 Working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100 sets per months
Product Description

LIYI 1000-1800Degree Electric Drying Oven LIYI Inert Atmosphere Heat Treatment



Product Description

This series of equipment is suitable for scientific research institutions, colleges and universities, industrial and mining enterprises ideal experimental and production equipment. It mainly used in high temperature precision annealing, micro-crystallization, ceramic glaze preparation, mold annealing, powder metallurgy, plastic powder foam test, sintering of nanometer materials, quenching of metal parts and all heat treatment required by high temperature technology.



Characteristics:

1. The double-layer forced air-cooling structure of the furnace shell is close to the room temperature at the time of operation. The appearance is sprayed with high-temperature and high-quality paint, and is not easy to fade. The door of the furnace is protected by stainless steel cover for a long time without blackening and easy to maintain.

2. Integrated compact design, step splicing structure, in accordance with the law of mechanics, heating force is uniform, heat is not easy to lose.

3. High quality and high alumina polycrystalline ceramic fiber (alumina > 95%), resistant to rapid cooling and heat preservation



Specifications

Model LY-16-17TP LY-16-18TP LY-16-19TP
Furnace size(W*H*D)mm 150*150*80 200*150*150 300*200*200
Outer size(W*H*D)mm 735*750*1200 700*670*930 750*660*1020
Weight(Kg) 155 190 300
power rating 3KW 5KW 9KW
Power 220V 50/60HZ
Temperature control precision ±1
vacuum degree -0.1MPa
end-use temperature maximum temperature 1800℃
heating rate 0--30℃/min(recommended less than 20/min)
Thermocouple Type B
heating element Silicon molybdenum rod
Display mode Color LED display
gasket ring Fluorine ring
vacuum pump Oil-immersed single rotary vane vacuum pump
Measuring mode mechanical pressure gauge
Furnace material High alumina polycrystalline ceramic fiber
Furnace structure double-layer forced air-cooling structure



LIYI 1700 Degree Optional Sizes With Vacuum Pump Inert Gas Atmosphere Vacuum Muffle Furnace
