LIYI Explosion Proof High And Low Temperature Test Chamber Constant Temperature And Humidity Test Chamber
Product overview:
The battery extruding and needling machine is applicable to simulate the situation of battery being squeezed and punctured when various batteries are used, transported, stored or treated with household wastes.
The extrusion direction of extrusion test shall comply with the following rules: one battery is extruded only once, and the battery is qualified if it does not explode or ignite.
1. For cylindrical batteries, the longitudinal axis of the extruded battery shall be parallel to the two flat plates of the extrusion device;
2. For square and soft packed batteries, only the wide surface of the battery shall be squeezed;
3. For coin type or button type batteries, the upper and lower planes of the battery shall be pressed parallel to the flat plate. The needling test shall be carried out under the environment of 20 ℃± 5 ℃. The battery shall be placed on the clamp and the diameter of φ 3- φ An 8mm non-corrosive steel needle is inserted into the center of the battery surface at the speed of 10mm / s-40mm / s, and the test results are observed at any time. The battery is qualified if it does not explode or ignite. The battery extrusion tester complies with gb31241-2014 and other standards.
According to standard:
GB 31241-2014,GB/T 8897.4-2008,YD/T 2344.1-2011,GB/T 21966-2008,MT/T 1051-2007,YD 1268-2003,GB/T 19521.11-2005,YDB 032-2009,UL 1642,UL 2054,IEC 62281,IEC 60086
Specifications:
| 1. Name | Temperature Humidity Test Chamber |
| 2. Model | LY-8001B-150L |
| 3. Sample limit |
This test equipment prohibits: 1. Test or storage of samples of flammable and volatile substances 2. Testing or storage of samples of corrosive substances 3. Testing or storage of biological samples 4. Test or storage of strong electromagnetic emission source samples |
| 4. Volume, size and weight | |
| 4.1. Nominal internal volume | 150L |
| 4.2. Inner dimension | W500*H600*D500mm |
| 4.3. Overall dimensions | About 980*1080*1550mm(W*D*H) |
| 4.4. Weight | About 250kg |
| 5. Performance | |
|
5.1. Test environment conditions 5.2. Test method |
The ambient temperature is + 25 ℃, the relative humidity is ≤ 85%, and there is no sample in the test chamber GB / T 5170.2-1996 temperature test equipment, GB / t2423.2-2008 (iec60068-2-2:2007) high temperature test method BB Gjb150.3-1986 high temperature test GB / t2423.1-2008 (iec60068-2-1:2007) low temperature test method ab Gjb150.4-1986 low temperature test GJB150.9-1986 thermal test GB / t2423.3-2006 (iec60068-2-78:2007) constant damp heat test method cab GB / t2423.4-2008 (iec60068-2-30:2005) alternating damp heat test method |
| 5.2. Temperature range | -40℃→+150℃ |
| 5.3. Humidity range | 20%-98%RH |
| 5.4. Temperature fluctuation | ±0.5℃ |
| 5.5. Humidity fluctuation | ±2.5% |
| 5.6. Temperature deviation | ±2.0℃ |
| 5.7. Humidity deviation | ±3.0%RH |
